917-23-7 分子结构
点击图片或这里关闭

2,7,12,17-tetraphenyl-21,22,23,24-tetraazapentacyclo[16.2.1.1^{3,6}.1^{8,11}.1^{13,16}]tetracosa-1,3,5,7,9,11(23),12,14,16,18(21),19-undecaene

ChemBase编号:75225
分子式:C44H30N4
平均质量:614.7358
单一同位素质量:614.24704698
SMILES和InChIs

SMILES:
N1=C2/C(=c\3/[nH]/c(=C(\c4ccccc4)/C4=N/C(=C(/c5ccccc5)\c5ccc([nH]5)/C(=C\1/C=C2)/c1ccccc1)/C=C4)/cc3)/c1ccccc1
Canonical SMILES:
c1ccc(cc1)/C/1=C/2\C=CC(=N2)/C(=c/2\cc/c(=C(\C3=N/C(=C(\c4[nH]c1cc4)/c1ccccc1)/C=C3)/c1ccccc1)/[nH]2)/c1ccccc1
InChI:
InChI=1S/C44H30N4/c1-5-13-29(14-6-1)41-33-21-23-35(45-33)42(30-15-7-2-8-16-30)37-25-27-39(47-37)44(32-19-11-4-12-20-32)40-28-26-38(48-40)43(31-17-9-3-10-18-31)36-24-22-34(41)46-36/h1-28,45,48H/b41-33-,41-34-,42-35-,42-37-,43-36-,43-38+,44-39-,44-40+
InChIKey:
YNHJECZULSZAQK-AAZAXIOTSA-N

引用这个纪录

CBID:75225 http://www.chembase.cn/molecule-75225.html

Collapse All Expand All

名称和登记号

名称和登记号

名称 登记号
IUPAC标准名
2,7,12,17-tetraphenyl-21,22,23,24-tetraazapentacyclo[16.2.1.1^{3,6}.1^{8,11}.1^{13,16}]tetracosa-1,3,5,7,9,11(23),12,14,16,18(21),19-undecaene
2,7,12,17-tetraphenyl-21,22,23,24-tetraazapentacyclo[16.2.1.13,6.18,11.113,16]tetracosa-1,3,5,7,9,11(23),12,14,16,18(21),19-undecaene
IUPAC传统名
tetraphenylporphyrin
别名
四苯基卟啉
内消旋-四苯基扑吩, low chlorin
meso-Tetraphenylporphine, low chlorin
TETRAPHENYL PORPHINE
5,10,15,20-Tetraphenylporphin
TPP
meso-Tetraphenylporphyrin
meso-Tetraphenylporphine, low chlorine
5,10,15,20-Tetraphenyl-21H,23H-porphine
meso-Tetraphenylporphyrin
5,10,15,20-Tetraphenyl-21H,23H-porphine
CAS号
917-23-7
20998-75-8
EC号
213-025-9
MDL号
MFCD00011680
Beilstein号
379542
PubChem SID
24854864
24889047
24889048
162040143
24849899
PubChem CID
70186

理论计算性质

理论计算性质

JChem
LogD (pH = 7.4) 11.219986  Log P 11.220981
摩尔折射率 193.0014 cm3 极化性 85.83062 Å3
极化表面积 57.36 Å2 可自由旋转的化学键
里宾斯基五规则 false  Acid pKa 14.33949
质子受体 质子供体
LogD (pH = 5.5) 11.145424

分子性质

分子性质

理化性质 安全信息 药理学性质 产品相关信息 生物活性(PubChem)
溶解度
Do you have solubility information on this product that you would like to share? expand 查看数据来源
熔点
>300 °C(lit.) expand 查看数据来源
449-451°C expand 查看数据来源
紫外吸收波长
λmax 415 nm expand 查看数据来源
λmax 514 nm expand 查看数据来源
荧光
λex 420 nm; λem 651 nm in toluene expand 查看数据来源
MSDS下载
下载链接 expand 查看数据来源
下载链接 expand 查看数据来源
下载链接 expand 查看数据来源
下载链接 expand 查看数据来源
下载链接 expand 查看数据来源
德国WGK号
3 expand 查看数据来源
TSCA收录
expand 查看数据来源
个人保护装置
Eyeshields, Gloves, type N95 (US), type P1 (EN143) respirator filter expand 查看数据来源
保存温度
-20°C expand 查看数据来源
2-8°C expand 查看数据来源
相关基因信息
human ... TERT(7015) expand 查看数据来源
纯度
≥93% (HPLC) expand 查看数据来源
≥99% expand 查看数据来源
≥99.0% (HPLC) expand 查看数据来源
97% expand 查看数据来源
级别
for fluorescence expand 查看数据来源
质检报告
下载链接 expand 查看数据来源
适用性
suitable for fluorescence expand 查看数据来源
杂质
<0.1% corresponding chlorin expand 查看数据来源
≤0.5% chlorin expand 查看数据来源
1-3% corresponding chlorin expand 查看数据来源
产品线
BioReagent expand 查看数据来源
Empirical Formula (Hill Notation)
C44H30N4 expand 查看数据来源

详细说明

详细说明

MP Biomedicals MP Biomedicals Sigma Aldrich Sigma Aldrich
MP Biomedicals -  05221509 external link
MP Biomedicals Rare Chemical collection
Sigma Aldrich -  88071 external link
Analysis Note
In addition to the emission maximum at 651 nm, there is a lower maxima at 717 nm.
Other Notes
Sensitizer used for the photochemical generation of singlet oxygen1,2,3
Sigma Aldrich -  88072 external link
Analysis Note
In addition to the emission maximum at 651 nm, there is a lower maxima at 717 nm.
Application
Do you have application information on this product that you would like to share?
Sigma Aldrich -  247367 external link
包装
1 g in glass bottle
250 mg in glass bottle
Sigma Aldrich -  160997 external link
包装
1, 5 g in glass bottle
25 g in poly bottle
